bag 'n' box filling machine manufacturer
Bag in Box (BIB) Fillers Packaging Performance
*Typical 3L CPH
Purge/
Vacuum
Overview
TORR manual wine filling options

TORR 10 Manual Filling Stand

BIB 60 Designed to aid in filling pouches and bags and is available with three (3) sizes of spout grippers. No power required. Capacity 0.75 to 20-liters, and performance of 1-2 bags per minute.
TORR manual wine filling options

TORR 15Hand Uncap with Recap Device

BIB 70 Designed to assist in filling and recapping pouches or bags and has an additional lever to cap bags quickly and securely. Capacity 0.75 to 20-liters, and performance of 1-2 bags per minute.
TORR laboratory fluid & liquid filling options

TORR 100Laboratory Style Filling System

BIB 140 Designed to fill pouches and bags from 0.75 to 20-liter capacity. Nitrogen purge and vacuuming are available as options. 0.5 to 1 bag per minute dependent on operator agility and size. Piping is 316L stainless steel and is FDA/3A approved.
TORR semi manual filling options

TORR 110Semi Manual Bag and Pouch Filler

BIB 100 Designed to fill stand up SUP pouches with face mounted fill spouts and bags from 0.75 to 20-liter capacity. Turbine flow meter. Piping is 316L stainless steel and is FDA/3A approved. 110-Volt power is required, as well as compressed air and nitrogen required with vacuum. Performance is 2-4 bags per minute and is dependent on operator agility and size
TORR semi auto filling options

TORR 130Semi-Automatic Bag and Pouch Filler

BIB 210 An economical solution for accurate filling. Ships with 1” turning flow meter touch panel and PLC. Flow meter is FDA approved grade acetyl plastic. Magnetic flow option is available for hot fill or particulate products. Click for performance and utility requirements.
TORR semi auto filling options

TORR 140HAutomatic Bag Filler

BIB 360 Automated, medium volume BIB filler or standup pouches with face mounted fill gland filler. Ships with turbine flow meter and an Allen Bradley PLC. Optional vacuum and nitrogen purge virtually eliminates all oxygen contamination of liquids.
TORR semi auto filling options

TORR 140WAutomatic Bag Filler

BIB 600 Combines proven, robust and dependable mechanical design. Bags fed automatically. FDA approved food grade acetyl plastic turbine flow meter. Magnetic and mass flow meter available option. Operator interface is Allen Bradley PLC and PV touch screen. Operates in auto mode, manual, CIP operation, batch counting and fill volume adjustment.
TORR semi automatic wine filling options

TORR 145High Production Automatic Web Fed Bag Filler

BIB 800 Combines proven, robust, and dependable mechanical design. With high quality controls and pneumatics to provide 24/7 BIB automation solution. FDA sanitary compliant. Production is based on bag size. Utility needed 220 VAC single phase 50-60Hz @ 30amps, air is 7 CFM @ 90 PSI.
TORR automatic bag in box filling options

TORR 150High Production Fully Automatic Bag and Pouch Filler

BIB 960 Fully automatic BIB filler designed for high volume, 24/7 production. Fills 1.5 to 20-liter bags. An optional fully enclosed fill head is pressurized with nitrogen and virtually eliminates O2 contamination of liquids. Pressurized product balance tank for accurate fills optional. Powered conveyer moves boxes automatically to bag into box loader optional. Optional C1D2 Explosion Proof rating.
Fully auto bag in box wine filler systems

TORR 180High Production Fully Automatic Bag and Pouch Filler

BIB 1440 High output, twin head filler for 24/7 production. Fast, reliable, efficient. Unique double fill head assembly to increase efficiency without multiple bag feed sources. 10 inch touch screen interface. Available in a C1D2 explosion proof configuration for filling high alcohol products.
Stand Up Pouch Fillers Packaging Performance
*Typical 3L CPH
Purge/Vacuum
TORR manual wine filling options

TORR 10

SUP 60
TORR manual wine filling options

TORR 15

SUP 70
TORR laboratory fluid & liquid filling options

TORR 100

SUP 110
TORR semi manual filling options

TORR 110

SUP 120
TORR semi auto filling options

TORR 120

SUP 140
TORR semi auto filling options

TORR 125

SUP 160
TORR semi auto filling options

TORR 130

SUP 180
TORR semi auto filling options

TORR 140H

SUP 330
TORR semi auto filling options

TORR 145P

SUP 650
Aseptic Fillers
For Extended Shelf Life/ High Acid Liquid Foods
Packaging Purge/Vacuum
TORR manual wine filling options

TORR/Engi-O AC3

BIB
TORR manual wine filling options

TORR/Engi-O AC4

Bins
TORR manual wine filling options

TORR 170 ESL

BIB
TORR manual wine filling options

TORR/Engi-O AC5 Single Head

Drums
TORR laboratory fluid & liquid filling options

TORR/ Engi-O AC5 Twin

Bin/Drum
Aseptic Fillers
For Low Acid Liquid Foods
Packaging Purge/Vacuum
TORR manual wine filling options

TORR/Engi-O AM3

BIB/Drum
TORR manual wine filling options

TORR/Engi-O AM4

Drums
TORR manual wine filling options

TORR/Engi-O AM5 Single Head

Drums
TORR manual wine filling options

TORR/Engi-O AM5 Twin Head

Drums
TORR laboratory fluid & liquid filling options

TORR/Engi-O AM5 Twin with A6 Bag Feed

BIB/Drum/Tote
TORR semi manual filling options

TORR/Engi-O AM7 Twin Auto Web Bag

BIB
